Pacman AI

This project builds a program that can play the original 1980 Atari Pacman. The approaches used are Deep-Q-Learning and Neuroevolution of Augmenting Topologies

Running The Program

Use the Makefile to run various parts of this project.

• NEAT
  • Train - make neat-train
  • Test - make neat-test
• DQN
  • Train - make rl-train
  • Test - make rl-test
• Q Learning Demo - make q-learning

Alternative

main.py usage

python3 main.py [algorithm] [train/test]

Requirements

Install the requirements with

pip install -r requirements.txt

Alternative

sudo make install

NEAT - Neuroevolution of Augmenting Topologies

All files using NEAT are stored under NEAT/

Train the NEAT model:

make neat-train

Test the NEAT model:

make neat-test

Explanation

For an explanation on a project using the same algorithm watch this video.

Short Explanation

This program uses a mathematical model, called a neural network, which simulates the brain of a human being. A neural network works by taking inputs and outputting probabilities for each of the outputs. This can be accomplished by using a sigmoid function.



Neuroevolution of Augmenting Topologies, or NEAT is what this project uses. The way standard neuroevolution works is by randomly initializing a population of neural networks and using survival of the fittest to get the best model. The best networks in each generations are bred and some mutations are introduced. NEAT introduces features like speciation to make a much more effective neuroevolution model. Neuroevolution is known to do better than standard reinforcement learning models.

DQN - Deep Q-Learning

All files using DQN are stored under DQN/

Train the DQN model:

make rl-train

Test the DQN model:

make rl-test

Explanation

Q-Learning

Q-learning learns the action-value function Q(s, a): how good to take an action at a particular state. Here's what each term means:

• state - The observation you take from the environment. In this case, it would be an image of the Pacman game or the RAM of the Atari console.


• action - The program's output for this particular state. For example, an action would be to move left, up, right, or down in Pacman

• reward - A reward is a number that tells how good or bad an episode was. In this case, the reward can be the score.

• Q(s, a) - Q is called the action-value function. In Q Learning, we build an table, called the Q-Table for every state action pair. This Q Table helps determine what action to choose.

This kind of state-action-reward system where the next state depends on the previous state is called Markov Decision Process.

How Q-Learning Works

Deep-Q-Learning

Deep Q-learning is a special type of Q-Learning where the Q-function is learnt by a deep neural network. The input to the neural network is the state of the environment and the outputs are the Q-Values. The action with the maximum predicted Q-value is chosen as our action to be taken in the environment.
