App that enables TJBot to be your personal planner. Uses Google Calendar.
- Converses with user in a friendly, understandable way
- Provides recommendations about the timing, location, and invitees for an event based on your Google Calendar history.
- If the user chooses, adds the event to the user's Google Calendar
Required Hardware (links in instructables):
- Raspberry Pi 3
- USB Microphone (note: you may want one with a cord. See "Considerations" at the end of this README)
- Speaker (preferably Bluetooth)
- NeoPixel LED Light
- Servo Motor Please refer to this instructable to build your own TJBot. Next, you will need to configure your Raspberry Pi's audio. Please visit this instructable (Steps 1, 2, and 3) for configuring your Raspberry Pi's audio.
All of these services have at least a free plan. Some APIs have usage limits that can be expanded via a paid plan. This app uses:
- Watson Conversation
- Watson Text to Speech
- Watson Speech to Text
- Watson Natural Language Understanding
- Google Calendar
- Google People
- Google Maps
Make sure all the Raspberry Pi and Node software is up to date (can take about 30 min):
sudo apt-get update
sudo apt-get dist-upgrade
curl -sL https://deb.nodesource.com/setup_6.x | sudo -E bash -
sudo apt-get install -y nodejs
sudo apt-get install alsa-base alsa-utils libasound2-dev
Begin by cloning this repository: git clone https://github.com/DrewGregory/tjcalendar.git
Next, enter the directory: cd tjcalendar
Install necessary modules: npm install
Create a config file: cp config.default.js config.js
Edit the file and input your credentials: sudo nano config.js or open with text editor.
For security and ease, I often access my credentials on a separate computer and then transfer the credentials to the Raspberry Pi. Manually typing the credentials into the config file is enormously error prone. I would recommend taking remote control of your Pi from your comptuer via SSH and/or VNC.
- SSH requires you to be on the same network as your Pi. It also requires a minimal ability to traverse IP addresses. To learn more, visit https://www.raspberrypi.org/documentation/remote-access/ssh/
- VNC often works in conjunction with SSH, but VNC Viewer allows you to remotely control your Pi without IP addresses and via a separate network. To install VNC Viewer, visit: https://www.realvnc.com/download/viewer/windows/ and https://www.realvnc.com/download/vnc/raspberrypi/. For more information, visit here.
Please refer to the instructable above (Step 5). Note: You will have to add the Natural Language Understanding credentials as well.
Since this recipe accesses your Google Calendar and Contacts, you will need to pass OAuth2 tokens. These tokens verify your right to access user information. To begin this process, visit this quickstart (Step 1). You should have a client_secret.json file at the end of this step in your recipe directory (tjcalendar).
Watson Conversation consists of workspaces, or designated instructions for Watson Conversation to follow. The workspace file for this recipe is the "workspace.json" file. Open Watson Conversation in your browser through these steps:
- Sign into IBM Bluemix.
- Go to the menu and click "Dashboard."
- Click the Conversation Credentials.
- Click "Launch Tool."
- Click the button next to the "Create" button to import a workspace.
- Import the workspace.json file.
- Click the three dots in the resulting workspace shown on the dashboard and then "View Details."
- Copy and paste the WorkspaceID in your config.js file.
For more information, visit this instructable (Step 6).
Visit this page to add the API Key to your project. Note: This API key should be registered in the same project that has your OAuth2 client id.
To run the application, run sudo node tjcal from a terminal in the directory (cd tjcalendar).
The first time you run this application, you will have to sign into your Google account with the given link in the terminal. SSH/VNC can be particularly helpful in this scenario as well. Once you finish signing in, copy the resulting token in the browser and paste it into the terminal. Then press Enter. If the token is entered correctly, you will no longer have to enter your token on successive executions of the recipe. It will be saved locally on the Pi.
All interaction with TJBot is through speech. The possible commands are listed below. Since Watson Conversation uses intents, the recipe will work even if there is some variability in how you say the given command. Some commands:
- Greeting ("Hi TJ Bot!")
- Goodbye ("Goodbye TJ Bot")
- Thank You ("Thank You TJ Bot!")
- Features ("What can you do TJ Bot?")
To begin the recommendation process, input one of the three criteria of an event: when, where, or who. TJBot will handle the rest!
- Where ("I want to check out a past event" or "I want to try a restaurant")
- When ("I want to have an event from nine AM to ten AM")
- Who ("I want to invite three people")
If you have any questions, please contact me at djgregny@gmail.com or submit an issue to this repository. To revise/improve this recipe, feel free to fork it, make your revisions, and submit a pull request to this repository.
This recipe requires a lot of precision when conversing with TJBot. Sometimes STT can be error prone, and the placement of the microphone is not ideal to hear your voice. If you are struggling having TJBot understand you, I would recommend considering other USB microphones that would improve clarity. Some microphone ideas:
Improvement Ideas:
- Make chatbot even more dynamic to changes in recommendations (Watson Conversation)
- Improve efficacy of updating data
- Improve recommendations for new locations. (Consider using place.details in Google Maps)
- Use different Calendar API
