Tic-Tac-Tourney

Tic-Tac-Toe game logic with Random, Minimax, and Heuristic AI agents competing against a human player in a round-robin tournament. Explore agent dynamics and performance in matches against human opponent.

Overview:

The project aims to design and implement AI agents using Minimax, Minimax with Alpha-beta pruning, and Expectimax algorithms to play Tic-Tac-Toe optimally. These agents will compete against a human player, with the game logic relying on heuristic functions, random agents, and efficient algorithms. A tournament framework will orchestrate matchups between agents, tracking performance metrics such as execution time and the number of nodes explored. The deliverables include implementing game logic, AI agents, and the tournament framework, with evaluation focusing on flawless execution and tournament dominance based on win rates and performance metrics.

Team Members:

• Amjad Ali Kudsi & Surya Manjri

Game Layout:

We're setting up a scenario for Tic-tac-toe where we'll train an agent to play against us. Our agent aims to minimize its utility, while we'll develop a strategy to maximize our own utility. To enhance the agent's decision-making beyond simple minimax, we'll employ alpha-beta pruning and expectimax.

In this game, the state comprises the board positions of both the agent and its opponent. Initially, we'll have a 3x3 board with zeros indicating available positions, updating them to 1 when we make a move and to -1 when the agent makes a move. Actions represent available positions based on the current board state. Rewards range from 0 to 1 and are given only at the end of the game. Victory is achieved by placing three marks in a horizontal, vertical, or diagonal row.

Agents Used:

1) Minimax Algorithm:

Minimax is a decision-making algorithm commonly used in two-player, zero-sum games like Tic-tac-toe or Chess. It works by recursively evaluating all possible future moves and choosing the one that maximizes the player's chances of winning while minimizing the opponent's chances. It assumes the opponent will also make optimal moves, resulting in a sequence of moves that leads to the best possible outcome for the player.

2) Minimax with Alpha-Beta Pruning:

Minimax with alpha-beta pruning is an enhancement of the basic minimax algorithm that reduces the number of nodes evaluated in the game tree. It maintains two additional parameters, alpha and beta, representing the minimum score that the maximizing player is assured of and the maximum score that the minimizing player is assured of, respectively. As the algorithm progresses, it prunes branches of the game tree that are guaranteed to be worse than previously examined branches, thus significantly reducing the search space while still finding the optimal move. This makes it more efficient than basic minimax, especially in deeper search trees.

3) Expectimax Algorithm:

Expectimax is an extension of the minimax algorithm tailored for decision-making in games involving uncertainty or randomness. Unlike minimax, which assumes that opponents always make optimal moves, expectimax acknowledges the presence of chance nodes representing random events or opponents with imperfect information.

In expectimax, the maximizing player still aims to maximize its utility, but it does so by considering all possible outcomes and their associated probabilities. This means that instead of assuming opponents always make the best moves, expectimax computes the expected utility by averaging over all possible outcomes, weighted by their probabilities.

Project Explanatory Video:

•

Project Structure:

• Python File: final_version.py

  • This Python file contains the entire code of execution.

• Presentation: AI Project 1 Final.pptx

  • A presentation summarizing the execution of this project.

• Screenshots: (Screenshots Folder)

  • Screenshots of the project execution.

  • Start:

  •

  • Minimax Search Algorithm:

  •

  • Wrong Inputs from user:

  •

  • Minimax Search Algorithm using Alpha-Beta Pruning:

  •

  • Expectimax Algorithm:

  •

  • Final Results:

  •

  • Further Enhancements: (Work in Progress!)

  •

Instructions for running this project:

Run the final_version.py

Project requirements:

• Latest version of Python (version 3.11.4 was utilized during development).
• Packages like Math, Random, Platform, Time and OS must be installed prior to usage.

Feel free to explore each section according to your interests. If you have any questions or suggestions, please contact the team members.

Thank you for exploring our project!
